DELTA KITS Ignite Flashlight Windshield Mount

Delta kits
147071039
$15.00
Powerful 2.75″ diameter vacuum cup mounts securely to glass. Multi-point adjustability. Holds Ignite LED UV flashlight style lamp at proper distance and angle for optimal curingReplacement Parts:16151 Ignite Mount Clip16152 Ignite Mount Vacuum CupFrom the ArchivesVacuum Cup Lesson 101Occasionally, we receive questions regarding the differences between suction cups and vacuum...
$15.00

Free Shipping

Free USA standard shipping on orders

Free Returns

Learn More.

Powerful 2.75″ diameter vacuum cup mounts securely to glass. Multi-point adjustability. Holds Ignite LED UV flashlight style lamp at proper distance and angle for optimal curing

Replacement Parts:
16151 Ignite Mount Clip
16152 Ignite Mount Vacuum Cup
From the Archives

Vacuum Cup Lesson 101
Occasionally, we receive questions regarding the differences between suction cups and vacuum cups. The best way to secure mounts with vacuum cups to the glass.

Suction Cups
Suction cups are a cup-shape device, usually made of rubber, silicone, or other flexible compounds, that use negative fluid pressure of air or water to adhere to nonporous surfaces and in the process create a partial vacuum. They are inexpensive and available in a variety of configurations. Suction cups require pressure to adhere to any given surface and the larger the cup the more pressure required for a secure mount in most cases.

Suction cups work well for attaching small lightweight parts like inspection mirrors, compact UV lights or other small parts that do not have a lot of back pressure against them.

Vacuum Cups
Vacuum cups are also typically made of rubber, silicone, or other flexible compounds. But unlike suction cups, feature a lever, button, or pump that pulls the center of the cup up away from the glass. Thereby creating a vacuum that holds the outer edges of the cup securely to the mounting surface. A vacuum cup is generally flatter, allowing more surface area to contact the glass, thus providing a more secure attachment with very little downward pressure regardless of the cup size. Attached properly, vacuum cups are also typically far more rigid than suction cups.

Vacuum cups are preferable over suction cups for attaching glass repair holding devices (bridges) to a broken windshield for several reasons:

Less pressure is required to attach a vacuum cup securely to the glass, significantly minimizing the chance of causing a crack to run.
The rigid mount holds the injector firmly in place against the glass, greatly reducing end seal leaks, and again, requires less pressure against the glass to minimize the chance of a crack out.
A properly mounted vacuum cup is far less likely to “come loose” and fall off the glass. Minimizes the potential damage to equipment and to the customer’s vehicle. Bridges have back pressure against the injector and the leveling screw(s) so maximum holding power is necessary.
A small vacuum cup has far more holding strength than a suction cup several times as large. Therefore, easier to carry, store and use.
Delta Kits uses high-quality vacuum cups on all mounts and bridges. Ensuring a stronger and more reliable adherence to the glass. While many Delta Kits UV lights feature factory mounted suction cups for cost-effectiveness and convenience. Versatile vacuum cup mounts are available and adaptable to all Delta Kits UV lights.
  • Powerful 2.75″ diameter vacuum cup mounts securely to glass with it’s multi-point adjustability.
  • The Ignite Flashlight Windshield Mount features a superior holding strength for the professional windshield repair technician.
  • Holds Ignite LED UV lamp at proper distance and angle for optimal resin curing action.
